Elektror S-LP Stainless Steel Centrifugal Fan

Technical description

The S-LP is a high efficiency centrifugal fan with a steel casing and backward-curved rotor, for process air up to 300 m3/min and 4,800 Pa. Efficiency is high and energy consumption correspondingly low.

Because the casing and rotor are steel rather than aluminium, the range also suits corrosive and hygienic process air where a standard aluminium unit would not survive.

Key features

• High efficiency, low energy consumption
• Steel casing and backward-curved steel rotor
• Variable interface possibilities
• Models: S-LP 133/62, 146/74, 160/62, 180/74, 200/74, 200/92, 215/92, 225/92

Typical applications

• Chemical and petrochemical process air
• Pharmaceutical and hygienic production
• Corrosive waste gas extraction
• Drying and dehumidification

Model selection

Flow, differential pressure and motor rating depend on the impeller stage and the motor fitted. Send us the duty point — required flow, pressure or vacuum level, conveyed media, temperature, voltage and area classification — and we will confirm the exact model, stage count and motor.

Supply scope

• Complete unit with motor, mounting feet and terminal box
• Inlet and outlet silencers, filters and flexible connectors available
• Spare parts, seals, impellers, bearings and wearing parts held for after-sales
• Documentation, wiring diagram and commissioning guidance supplied with the unit
